Seismic floor expansion joint suitable for all types of construction sites with pedestrian or light cart traffic. This model is available for initial openings from 50mm to 500mm. For larger openings, please consult us.
Technical sheet
BIM File
CAD Drawing
Download our brochures
These documents are reserved for members
REFERENCES JDH 5.190
5.190-050
5.190-080
5.190-100
5.190-150
5.190-200
5.190-250
5.190-300
5.190-350
5.190-400
5.190-450
5.190-500
GAP UP TO (MM) W
50
80
100
150
200
250
300
350
400
450
500
MOVEMENTS (MM)
+25/-25
+40/-40
+50/-50
+75/-75
+100/-100
+125/-125
+150/-150
+175/-175
+200/-200
+225/-225
+250/-250
VISIBLE WIDTH (MM) S
348
348
348
406
456
676
726
892
1026
1087
1226
TOTAL WIDTH (MM) B
407
407
407
465
515
726
776
943
1076
1138
1276
HEIGHT (MM) H
51
51
51
51
51
64
64
64
64
64
64
LOAD-BEARING CAPACITIES
The load capacity is always given for a joint in its initial position. In case of opening movements, the load capacity is strongly reduced and the product will only be suitable for light pedestrian traffic. The indicated load values are based on vehicles with pneumatic wheels with a contact area of 200x200 mm.
